Temperature range：5～35℃
Cooling capacity：300W
Circulating flowrate：6-15L/min
Temperature stability：±0.1
Strength guarantee: 20 years of manufacturing experience,
24-hour after-sales service
Online Consultation
Laser chiller is mainly used in laser marking machine, laser engraving machine, laser welding machine, laser inkjet printer, laser cutting machine and other laser processing equipment. It can accurately control the temperature required by the laser equipment, so as to ensure the normal operation of the laser equipment.
Laser water chiller is a kind of refrigeration equipment, which can provide heating, refrigeration, circulation and constant temperature cooling water.
The working principle of the laser water chiller is to inject a certain amount of water into the water tank inside the chiller, cool the water through the chiller refrigeration system, and then send the low-temperature cooling water to the equipment to be cooled by the water pump. The cooling water of the chiller takes away the heat, increases the temperature, and then flows back to the water tank to achieve cooling. The cooling water temperature can be automatically adjusted according to requirements, and water can be saved after long-term use. Therefore, the laser chiller is a standard energy-saving refrigeration equipment.
| Model | Temperature range (℃) |
Temperature stability (℃) |
Cooling capacity (W) |
Filling volume (L) |
Circulating pressure (bar) |
Circulating flowrate (L/min) |
Size of connection (Rc) |
Net weight (kg) |
Dimension W×D×H (mm) |
|---|---|---|---|---|---|---|---|---|---|
| LX-150Z | 5~35 | ±0.1 | 150 | 1 | 0.3/0.45 | 0～10 | 1/4〞 | 16 | 230×280×380 |
| LX-300Z | 5～35 | ±0.1 | 300 | 4 | 0~0.8 | 0~15 | 1/2〞 | 30 | 230×475×475 |
| LX-300P | 5～35 | ±0.1 | 300 | 4 | 0～4.0 | 0～6 | 1/2〞 | 30 | 230×475×475 |
| LX-600Z | 5～35 | ±0.1 | 600 | 5 | 0～0.8 | 0～15 | 1/2〞 | 35 | 290×550×540 |
| LX-1000Z | 5～35 | ±0.1 | 1000 | 8 | 0～3.7 | 0～28 | 1/2〞 | 56 | 345×620×600 |
| LX-2000Z | 5～35 | ±0.1 | 2000 | 14 | 0～3.7 | 0～28 | 1/2〞 | 60 | 385×655×685 |
| LX-3000Z | 5～35 | ±0.1 | 3000 | 40 | 0～3.7 | 0～45 | 1/2〞 | 90 | 425×750×765 |
| LX-5000Z | 5～35 | ±0.1 | 5000 | 40 | 0～3.7 | 0～45 | 1/2〞 | 109 | 465×855×805 |
Offers temperature, pressure, flow rate, conductivity and other options.
Standard thread connection, can be converted to domestic and foreign British or metric joints.
Independent design, independent production, completely independent intellectual property rights.
Multi-purpose one machine can cool multiple user equipment.
* Fully closed refrigeration system, stable work, reliable performance
* Digital display and control, high temperature control precision, uniform temperature
* Microprocessor PID intelligent algorithm, with learning function, better suitable for user needs
* Adopt ultra quiet circulating water pump, the whole machine work quietly, low noise
* High performance refrigeration system and pump circulation system, suitable for long continuous work
* Closed water tank and pipeline structure to avoid coolant pollution and oxidation
* Standard stainless steel tank, can be equipped with a variety of specifications of connectors and hoses, external closed circuit circulation.
* Real-time display of working status and alarm status
* Optional flow display, flow alarm, improve supporting security performance
* Optional RS485 communication, easy to connect to the host computer
